38
Specifications
Model: MVP-50P
Weight: 1.9 Lbs.
Environmental: Designed to TSO (DO-160)
Software: Designed and Documented to TSO (DO-178B)
Power Requirements: 7.5 to 30 Volts, 0.3 amps @ 24V (Typ), 0.6 amps @ 12 Volts (Typ).
USB Port: For USB Memory Sticks use only.
Display: Active Matrix TFT, 262,144 colors, Sunlight readable
Backlight: Enternal electric eye and external control line.
Model: EDC-33P-4/6
Weight: 1.0 Lbs
Environmental: Designed to TSO (DO-160)
Software: Designed and Documented to TSO (DO-178B)
Power Requirements: 7.5 to 30 Volts, 0.1 amps (Typ).
Inputs:
Volts: Measured on the power lead to the EDC.
Amps: +/- 2.5V differential input, +/- 90 Volt common mode operating range.
Fuel Flow: 2.5 volt trigger, 5.11K Ohm pullup to +5 Volts, 0 to 8.3K Hz.
2ea. RPM: May be configured for digital or mag pickup. Selectable jumper for 4 or 6 cylinder operation.
Over voltage protection, 3 Volt trigger, impedance = 2.06K with 1 volt pullup.
6ea. Pressure: 0 to 2.5 Volts differential input, impedance > 20M Ohms,
Common mode = 0 to 4 Volts.
17ea. Temperature: 0 to 2.5 Volts differential input, impedance = 12.1K Ohms,
Common mode = 0 to 4V.
4ea. Resistive Fuel Level: 0 to 18 Volts single ended input, impedance = 14.4K Ohms.
4ea. Capacitive Fuel Level: 0 to 6K Hz., 2.1 Volt trigger, impedance = 33.2K Ohms
