Eliwell Memory 1000 - Analogue Inputs

9MA10011 16/52
4.4.1 Analogue Inputs
Thismenushowsthelistofonboardanalogueinputs.
4.4.1 ANALOGUE INPUTS

01 ONBOARD-P1 |
02 ONBOARD-P2 |
03 ONBOARD-P3 |
04 ONBOARD-P4 |
05 ONBOARD-P5 |
06 ONBOARD-P6 |
07 ONBOARD-P7 |
08 ONBOARD-P8

SelecttherequiredanalogueinputusingtheUPandDOWNkeysandpressOK.
Apagedisplayingthefollowinginformationwillopen:
(exampleIndex01Input,pressureprobe).
4.4.1 ANALOGUE INPUTS

Index 1/8 |
Name ONBOARD-P1 |
Probetype 4..20mA |
UnitofmeasureBar |
Decimalpoints 1 |
Value=04mA 0.0 |
Value=20mA 30.0 |
Offset 0.7 |
Read 13.3 |
ViewText YES

• Index:InputIndex***
• Name:NameofInput.ThedefaultnamesareONBOARD-P1..ONBOARD-P8
andcanbemodiedasrequired(max.10characters)
• Probetype:setautomaticallybetween[ 4…20mA and NTC 103AT]
• Unit of Measure:seeUnits of Measure table
• Decimal Points:values[0…3]for4..20mA,[0…1]forNTC
• IfProbe Type=4…20mA:
- Value = 04 mA:indicatesstartofscale
- Value = 20 mAindicatesfullscale
• IfProbe Type=NTC:
• MinimumValue***
• MaximumValue***
• Offset:ProbesCalibration.Note:themodicationontheValueRead(seenext
item)isimmediate.
• Read Valuereadinrealtime***
• View Text:ifYESthenthevalueisenteredinalistofelementstobeviewedin
DefaultView.
***Read-onlyinformation.
