Eliwell Memory 1000 - Network 1; Print Config.; Network Mode; Self-Configuration

9MA10011 19/52
4.4.5 Print config.
4.4.5 ONBOARD CONFIGURATION
Doyouwanttoprint?
^=Yesv=No
Fromthis menu you can print the configurationof onboardinputs (seePrinter
section).

4.5 Network 1
N.B.:This menuis foruse byauthorized personnelonly. in fact,the networkof
compatibleTelevisdevicesconnectedviaRS485toMemory1000canbemodified
fromthismenu.
4.5 NETWORK 1
4.5.0 NetworkMode
4.5.1 Self-conguration
4.5.2 -----------------------
4.5.3 -----------------------
4.5.4 GeneralInfo*
4.5.5 units
4.5.6 Printcong.*
MenuavailableinmodelswithRS485only.
Thismenuallowsyoutoconfigure‘Network1’orthenetworkofcompatibleEliwell
TelevisdevicesconnectedviaserialportRS485toMemory1000.
4.5.0 Network Mode
4.5.0 NETWORK 1 MODE
Changedata
Delete Networkconfiguration
Networktype: Televis
Networkaddress 14:14
Max.units 15
ValuesmodiableonlyifREC=Off
• Network type:canbeDisabledorTelevis
• Network address:setnetworkaddress(MASTERTelevis)
4.5.1 Self-configuration
4.5.1 SELF-CONFIGURATION
Changedata
Delete Networkconfiguration
Networktype: Televis
Last Address 0:1
First Address 0:1
AutomaticproceduretorecognizecompatibleEliwellTelevisdevicesconnectedvia
theRS485serialporttoMemory1000.Theproceduremaytakeafewminutesto
self-conguredependingonthenumberofdevicesinthenetwork.
• Last address:setthevaluefortherstaddressassignedtodevicesinthenetwork.
