9. ELECTRICAL CONNECTIONS
9.1 General warnings
IMPORTANT!
Switch off the device before working on the electrical connections.
All electric work must be performed by a qualified electrician.
Toensureproperconnections,thefollowingwarningsmustbeobserved:
• Powersupply.
• Usecablesoftherightsizefortheterminalsused.
• Separatethecablesofprobesanddigitalinputsfrominductiveloadsand
highvoltageconnectionstopreventanyelectromagneticinterference.Donot
placeprobecablesnearanyelectricdevices(switches,meters,etc.).
• Makeconnectionsareshortaspossibleanddonotwindthemaround
electricallyconnectedparts.
• Donottouchelectroniccomponentsonboardstopreventthebuildupof
staticelectricity.
9.1.1 Power supply - High voltage output (relay).
Donotexceedthemaximumpermittedcurrent;forhigherloads,useacontactor
withsufficientpowercapacity.
Important!
Makesurethatpowersupplyisthecorrectvoltageforthedevice.

8.6.2 Serial data
Device name Data successfully exported
• Thefirsttimedataisexported,givetheMemory1000connectedaname.
• Click on transfer: data will be downloaded to the PC (this will take a few
minutes).
8.6.3 Tables / Graphs
Table Graphic
• TableorGraphdisplayformat.
• DefineaProfileintheFilterssection,selectareportandaviewdatadate.
• Selecttheresource(s)tobedisplayed.
• Youcanzoomonthegraphtoviewthex-yvaluesandconfigurethescale.
• Youcannowsavetheprofile,exportandprintthedata.
8.6.4 List of plants
• Whenmorethanoneplantismanaged,youcanselecttheplantthatyouwant
todownloadandsavedatafor.
