Eliwell Memory 1000 - Circuit Diagrams

9MA10011 38/52

9.2 Circuit diagrams
Thenumberofanalogueinputs,digitalinputsandalarmoutputs
depends on the Memory 1000 model (see section Annexe A -
ModelsandAccessories).
Modelli Base
Modelli Standard
sonde NTC
Modelli Standard
sonde NTC
+ Ingressi 4…20mA
Modelli RS485
Alimentazione
