Eliwell Memory 1000 - Connections with Pressure Transducers; Humidity Probes

9MA10011 40/52
9.2.2 Connections with pressure transducers / humidity probes
6
2 wires / 2 fili Power Supply from / da Memory 1000
Probe / Sensore
Signal / Segnale
12V
also for / anche per
EWPA 007-030
EWHS 280
EWHS 300
8
7 9
+12
IN
+12
IN
4 wires / 4 fili Power Supply from / da Memory 1000
6
8
7 9
+12
IN
+12
IN
10
GND
AI1
AI2
12V
T
RH (+)
GND (-)
3 wires / 3 fili Power Supply from / da Memory 1000
Probe / Sensore
Signal / Segnale
RH (+)
GND (-)
6
8
7 9
+12
IN
+12
IN
10
GND
AI1
Probe / Sensore
Signal / Segnale
RH (+)
GND (-)
6
8
7 9
+12
IN
+12
IN
10
GND
AI2
2 wires / 2 fili External Power Supply for Transducter / Trasduttore
Transducter / Trasduttore
Signal / Segnale
GND
Power Supply
for / per
Transducter / Trasduttore
6
8
7 9
+12
IN
+12
IN
