Eliwell Memory 1000 - Example of Print Onboard Resource Configuration

9MA10011 29/52
Example of print Description
Date Time (1) (2) (3) (4) (5)
----------------------------------
12/02/07 00:00 10.0 . . - .
00:01 10.5 * . - .
00:02 11.4 * . - .
00:03 11.7 * . - .
00:04 11.6 * . - .
00:05 10.9 * . - .
00:06 10.9 * . - .
00:07 11.0 * . - .
00:08 10.7 * . - .
00:09 10.5 * . - .
00:10 10.8 * . - .
(continued)
Theprintcolumnsdisplay
(fromlefttoright):
•Readingdate
•Readingtime
(1)Reading(intheunitof
measureselectedforthe
analogueinput)
(2)Anasterisk‘*’ifthe
readingisbelowthe
negativedelayedalarm
limitorabovethepositive
delayedalarmlimit
(3)Anasterisk‘*’ifthe
readingisbelowthe
negativeemergencyalarm
limitorabovethepositive
emergencyalarmlimit
(4)Notused
(5)An‘*’iftheuserhas
performedthealarm
acknowledgmentfunction
bypressingthekey
End of print
Attheendthefollowingmessage
appears
End of print
6.5.3 Example of Print Onboard Resource Configuration
Example of print Description
DATA LOGGER Page 01
12/02/2007 Time 13:56
Device Code 0000H 004CH
Print Device
Configuration
Printheader
Theheaderappears:
•atthestartofeachprint;
•atthetopofeachnewpage.
Theheaderincludes:
•Theproductnameandpagenumber
•Startprintdateandtime
•Theserialnumberofthedevice
•Thetypeofconfigurationbeingprinted,which
canbeeither:OnboardResourceorNetwork1
•Thedateandtimetheprintconfiguration
wascreated/edited
*************************
Onboard resources
*************************
Date : 12/02/2007
Time: 13:56:50
ANALOGUE INPUTS
Inputs available: 8
Inputs managed: 2
DIGITAL INPUTS
Inputs available: 2
Inputs managed: 2
Analogue input : 1
--------------------------
PrintConfigurationisorganisedhierarchically
tomakeiteasiertounderstand:
•Totalnumberofanalogueinputsavailable
andmanaged
•SettingsforAnalogueInputs
