9MA10011 30/52
Example of print Description
Connector/Terminal: AI01
Probe type: 4..20 mA
Unit of Measure : Bar
Decimal Points : 1
Probe name: CONDENSING
Min. value : 0.0
Max. value : 30.0
Alarm Output : 1
Delay (m) : 0
Alarm hysteresis: 0.1
Posit. Emerg. : 10.0
Posit. Delay: 8.0
Negat. Delay: 0.0
Negat. Emerg. : 0.0
Analogue input : 2
---------------------------
Connector/Terminal: AI02
Probe type: 4..20 mA
Unit of Measure : Bar
Decimal Points : 1
Probe name: SUCTION
Min. value : -0.5
Max. value : 7.0
Alarm Output : 1
Delay (m) : 0
Alarm hysteresis: 0.1
Posit. Emerg. : 7.0
Posit. Delay: 6.5
Negat. Delay: 0.0
Negat. Emerg. : 0.0
Digital input : 1
---------------------------
•…andforAnalogueAlarms
Example of print Description
Connector/Terminal: AI03
Default State : N.A.
Name : N0-D1
Alarm Output : 1
Delay (m) : 0
Digital input : 2
---------------------------
•SettingsforDigitalInputsand
•Digitalalarms
Connector/Terminal: AI04
Default State : N.C.
Name : N0-D2
Alarm Output : 1
Delay (m) : 0
End of print
Attheendthefollowingmessageappears
End of print
