Eliwell Memory 1000 - Page 24

9MA10011 24/52
5.4 Network 1
Definition:Network1=RS485toexpandinputs
5.4 NETWORK PARAMETERS
Timeout(mS) 640
Attempts 3
Alarmtime(S)
Network1&2 30
MenuavailableformodelswithRS485only
Fromthismenu,youcansettheoperatingparametersforNetwork 1.
Seetheself-congurationproceduretoo:
• Timeout (ms):valueofthetimeoutfortheresponsefromcontrollers.
• Attempts:from0to3=numberoftimestheTelevisslavetriestosenddata
beforegeneratinga‘No-Lnk’error(value0=oneattempt,3=fourattempts).
• Alarm time (s)(Network1&2):valuesfrom10to300secondsin10-second
steps=setsthefrequencywithwhichtheDataloggerrunsafullnetworkscan
ofalarmstatesineachresource.
5.5 Not used
5.6 Network 3
Definition:Network3=RS232porttodownloaddata
5.6 NETWORK PARAMETERS
Networktype: ModbusSlave
BaudRate 19200
Slave210address
MenuavailableformodelswithRS232only
Fromthismenu,youcansetthecommunicationnetworkforNetwork3:
To ensure the data download software runs correctly, leave the original
configurationasshownintheexample.
5.7 Not used
5.8 Passwords
See user interface chapter
5.9 Not used
