Elliott Digger Derrick - BILL OF MATERIALS

14
BILL OF MATERIALS
ITEM NO. TWI PART NO. QTY. DESCRIPTION
1 29792 20 CAPSCREW
2 42134 2 SUPPORT ROD
3 29973 1 RETAINING RING
4 4142 1 OUTPUT GEAR SET
4-1 41755 1 OUTPUT CARRIER
4-2 41728 3 OUTPUT PLANET GEAR
4-3 41747 3 PLANET PIN
4-4 41716 3 RETAINING RING
4-5 41769 1 PLATE
4-6 41717 6 BEARING
4-7 41739 3 SPACER
4-8 939249 6 RACE
41731 1 DRUM (9 3/4” barrel, 16 3/8” flange)
41996 1 DRUM (10 5/8” barrel, 20” flange)
42128 1 DRUM (9 3/4” barrel, 15” flange)
42413 1 DRUM (10 5/8” barrel, 16 3/8” flange)
42471 1 DRUM (10 5/8” barrel, 18” flange)
42510 1 DRUM (9 3/4” barrel, 13 3/4” flange)
5
43171 1 DRUM (10 5/8” barrel, 14” flange)
6 41722 2 RACE
7 42393 1 BASE
41734 1 INPUT SUN GEAR (41 & 59:1 Ratios)
41735 1 INPUT SUN GEAR (29:1 Ratios)
8
41736 1 INPUT SUN GEAR (21:1 Ratios)
9 20524 16 CAPSCREW
10 41738 1 BRAKE PISTON
11 41740 1 BRAKE DRIVER
12 41723 2 RACE
13 26980 2 RETAINING RING
41742 1 OUTPUT SUN GEAR (21, 29 & 41:1
Ratios) 14
41741 1 OUTPUT SUN GEAR (59:1 Ratios)
15 41743 2 BUSHING
16 32765 7 FRICTION DISC
17 26854 8 STATOR PLATE
18 41749 1 BRAKE HOUSING
19 41721 2 OIL SEAL
20 29043 2 RETAINING RING
21 41718 12 BRAKE SPRING
22 41720 2 OIL SEAL
23 41752 1 BEARING CARRIER
24 939452 1 O-RING
25 34550 2 BALL BEARING
26 CONTACT FACTORY 2 SIDE PLATE
