2.3.1 Group “A” Fault Codes
NOTE: Check and repair “B” and “C” group faults before proceeding with group “A” fault finding sensors.
Group “A” fault codes represent faults detected for analog sensors.
The following chart details all the available codes in the left column and the actions to take in the right
column.
FAULT
CODE
SWING
SENSOR
BOOM
ANGLE
SENSOR
EXTENSION
SENSOR
TDX 1
ROD
PRESSURE
TDX 0
PISTON
PRESSURE
ACTION
000
No Fault Found
None
001
X
Replace the Computer.
002
X
003
X
X
004
X
Refer to the Extension
Calibration instructions.
008
X
Refer to Angle Sensor in
Calibration instructions.
012
X X
Refer to Extension, Angle and
Reeling Drum Calibration
instructions.
2.3.2 Group “B” Fault Codes
Group “B” fault codes represent faults detected for internal analog functions and power feeds to the
function kickout and anti-two block switches.
The following chart details all of the available codes in the left column and the actions to take in the
right column.
FAULT
CODE
FKO
POWER
FEED
ATB
POWER
FEED
DISPLAY
CONSOLE
ADC 2
INTERNAL
FAULT
ADC 1
INTERNAL
FAULT
ACTION
016 X
Check Crane Circuit
Breakers
2.3.3 Group “C” Fault Codes
Group “C” fault codes represent faults detected for internal computer memories. The following chart
details all the available codes in the left column and the actions to take in the right column.
FAULT
CODE
SERIAL
EEPROM
CRANE
DATA
RAM
DUTY
DATA
PROGRAM
ACTION
000
NO FAULT FOUND
NONE
008
X
Erase Crane Data
016
X
Replace the Computer
