16 10-2014-2.1 - D 7960 N - V60N www.hawe.de | 2015
Pressure and delivery flow
Operating pressure
See Chapter 2, "Available versions, main data"
Geometric displacement
See Chapter 2, "Available versions, main data"
Dimensions
Type V60N With controller (kg)
060 24
090 27
110 30
130 30.8
Additional parameters
Nominal sizeDescription
060 090 110 130
Max. swash plate angle
20.5° 21.5° 21.5° 21.5°
Absolute inlet pressure required in open circuit
0.85 bar 0.85 bar 0.85 bar 0.85 bar
Max. permissible housing pressure (static/dynamic)
2 bar/3 bar 2 bar/3 bar 2 bar/3 bar 2 bar/3 bar
Max. permissible inlet pressure (static/dynamic)
20 bar/30 bar 20 bar/30 bar 20 bar/30 bar 20 bar/30 bar
Max. speed during suction operation and max. swash plate angle at
1 bar abs. Inlet pressure
2500 rpm 2300 rpm 2200 rpm 2100 rpm
Max. speed with zero stroke and 1 bar abs. Inlet pressure
3000 rpm 3000 rpm 3000 rpm 3000 rpm
Min. speed in continuous operation
500 rpm 500 rpm 500 rpm 500 rpm
Required drive torque at 100 bar
100 Nm 151 Nm 184 Nm 230 Nm
Drive power at 250 bar and 2000 rpm
53 kW 79.5 kW 97.2 kW 120 kW
Weight torque
30 Nm 35.5 Nm 40 Nm 40 Nm
Inertia torque
0.005 kg m
2
0.008 kg m
2
0.01 kg m
2
0.011 kg m
2
Noise level at 250 bar, 1500 rpm and max. swash plate angle
(measured in acoustic measurement chamber according to DIN ISO
4412, measurement distance 1 m)
75 dB(A) 75 dB(A) 75 dB(A) 75 dB(A)
Max. permissible drive/output torque
Nominal sizeDescription
060 090 110 130
Parallel key splined
shaft D
Drive/output
430 Nm/100 Nm 530 Nm/530 Nm 800 Nm/600 Nm 800 Nm/700 Nm
Spline shaft M Drive/output
-- 530 Nm/530 Nm 530 Nm/530 Nm --
Spline shaft H Drive/output
210 Nm/100 Nm -- -- --
Spline shaft U Drive/output
210 Nm/100 Nm -- -- --
Spline shaft T Drive/output
340 Nm/100 Nm -- -- --
Spline shaft S Drive/output
430 Nm/100 Nm 530 Nm/530 Nm 640 Nm/600 Nm 640 Nm/640 Nm
Spline shaft Q Drive/output
-- 530 Nm/530 Nm 900 Nm/600 Nm 900 Nm/700 Nm
