Elmo MX-P2 User Manual

25
Resolution
Manual
-
-
✔
✔
Flicker
60Hz / 50Hz（Default setting: 60Hz）
✔
-
✔
✔
Contrast
Possible（Set value 0～20） Default
value: 14
-
-
✔
✔
Hue
Possible（Set value -180～180）
Default value: 0
-
-
✔
✔
Saturation
Possible（Set value 0～31） Default
value: 26
-
-
✔
✔
Definition
Possible（Set value 1～15） Default
value: 5
-
-
✔
✔
Gamma
Possible（Set value 100～200） Default
value: 120
-
-
✔
✔
White balance
Auto/Manual（Set value 2000～8000）
Default setting: Auto 6500
-
-
✔
✔
Backlight
compensation
ON/OFF Default setting: OFF
-
-
✔
✔
Low-light
compensation
ON/OFF Default setting: OFF
-
-
✔
✔
Factory setting
Possible
✔※1
-
✔
✔
※1 The product will be reset to factory default when the power is turned on while the LED
lighting button and the Freeze button are pressed at the same time.
(Items to be reset: Brightness, Image rotation, Contrast, Hue, Saturation, Definition,
Gamma, White balance, Backlight compensation, Focus, Exposure)
■ILLUMINATION DEVICE
■OTHER FUNCTIONS
Item
Specifications
LED lighting
White LED
Item
Specifications
USB
USB 2.0 compliant ／ USB 3.0 compliant
Transfer speed
USB3.0 Super Speed (5Gbps)
USB2.0 High Speed (480Mbps)
※The actual transfer speed may vary depending on the performance
of your computer and the status of the USB bus.
Operating
temperature
0℃～+40℃
Humidity
30％～85％ (No condensation）

Elmo MX-P2 Specifications

General

Operating voltage	5 V
Power supply type	DC
Interface	-
USB connector type	Micro-USB B
Auto focus	Yes
Digital zoom	16 x
Shooting area (WxD)	373.38 x 281.94 mm
Maximum aperture number	2
Maximum frame rate	60 fps
Optical sensor size	- \
Supported graphics resolutions	1920 x 1080 (HD 1080), 3840 x 2160
Product color	White

Weight and Dimensions

Depth	81.28 mm
Width	342.9 mm
Height	302.26 mm
Weight	544.311 g
Dimensions folded (WxDxH)	289.56 x 81.28 x 22.86 mm
