Elna International Corps. SA 6004 Service manual
TEST PROGRAM
When all tests have been completed, the LCD displays: SELF - CHECK END.
Press the « VISUAL » button.
If no problems were detected during the test, the buzzer sounds and the LCD
displays:
CHECK OK!
If a problem was detected during the test, the LCD will display one several en-or
codes related the defect condition.
LIST 0F ERROR CODES DISPLAYED ON
THE LCD
COMPONENT TO CHECK OR REPLACE
“Error - A “ Circuit Board A
“Error - B “ Buttonhole Sensor
“Error - C “ Foot control
“Error - D “ Main Motor
“Error - K “ Circuit Board K
“Error - P “ Upper shaft Position Sensor
“Error - R “ Machine socket
“Error - X “ Zigzag Step Motor
“Error - Y “ Feed Step Motor
