64 Chapter 3
Removing the WLAN Module
1. See “Disassembly Overview” on page 62.
2. Disconnect the two (2) cables from the WLAN board.
3. Remove the one (1) screw.
Step Size Quantity Screw Type
WLAN Module Disassembly M2.0*3.0 1
