eMachines D732 - Remove the Lcd Hinges

84 Chapter 3
4. Lift the LCD panel clear of the LCD cover as shown.
Remove the LCD Hinges
1. See “Removing the LCD Panel” on page 83.
2. Remove the six (6) screws, three on each side. Separate the hinges from the LCD panel.
Step Size Quantity Screw Type
LCD Hinge
Disassembly
M2.0*3.0 6
