eMachines D732 - HDD Module M2-0.4*2; Removing the Hdd Module

68 Chapter 3
Removing the HDD Module
1. See “Disassembly Overview” on page 62.
2. Remove the one (1) screw securing the HDD module to the mainboard.
3. Using the pull-tab, slide the HDD module in the direction of the arrow to disconnect the interface.
Step Size Quantity Screw Type
HDD Module M2-0.4*2 1
