eMachines D732 - Removing the Thermal Module

72 Chapter 3
Removing the Thermal Module
1. See “Disassembly Overview” on page 62.
2. Disconnect the fan cable as shown.
3. Loosen the four (4) captive screws (in numerical order from 1 to 4) and remove the one (1) screw from the fan
module.
Step Size Quantity Screw Type
Thermal Module
Disassembly
M2.5*4.0 (green
callout)
1
2
3
1
4
