Chapter 3 59
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
NOTE: Use the process highlighted in red to access the Bluetooth module
Screw List
Step Screw Quantity Part No.
Lower Cover M2.5*6.5 17 86.ARE07.001
Battery Bay M2.0*3.0 6 86.ARE07.002
WLAN Module Disassembly M2.0*3.0 1 86.ARE07.002
USB Module Disassembly M2.5*4.0 1 86.ARE07.002
HDD Module M2-0.4*2 1 86.W4107.002
