Chapter 3 113
External Module Assembly Process
Replacing the ODD Module
1. Place the ODD bracket onto the ODD module and replace the two (2) screws to secure it.
2. Press the bezel into the tray, bottom edge first, to secure it to the ODD module.
Step Size Quantity Screw Type
ODD Bracket
Assembly
M2.0*3.0 2
