eMachines D732 - Replacing the Lcd Module

Chapter 3 103
Replacing the LCD Module
1. Place the upper cover onto the LCD module and lower into place. Lower the hinges so they are flush with the
hinge plates on the upper cover.
2. Replace the four (4) screws to secure the left and right hinges.
Step Size Quantity Screw Type
LCD Module
Assembly
M2.5*6.5 4
