eMachines E732 - Main Unit Assembly Process; Replacing the Bluetooth Module

Chapter 3 93
Main Unit Assembly Process
Replacing the Bluetooth Module
1. Lower the Bluetooth module onto the mainboard (1) and then push it against the metal post until firmly
attached (2).
2. Replace the one (1) screw to secure the Bluetooth module to the mainboard.
Step Size Quantity Screw Type
Bluetooth Module
Assembly
M2.0*3.0-I 1
1
2
