86 Chapter 3
Replacing the LCD Hinges
1. See “Removing the LCD Panel” on page 80.
2. Replace the four (4) screws, 2 on each side to secure the hinges.
Step Size Quantity Screw Type
LCD Hinge
Assembly
M2.0*3.0-I 4
