58 Chapter 3
Removing the WLAN Module
1. See “Disassembly Overview” on page 58.
2. Disconnect the two (2) cables from the WLAN module.
3. Remove the one (1) screw.
Step Size Quantity Screw Type
WLAN Module
Disassembly
M2.0*3.0-I 1
