eMachines E732 - Chassis Assembly

Chapter 6 143
Chassis Assembly
No. Description Acer P/N No. Description Acer P/N
1 LCD MODULE 6M.NCE07.003 8 LOWER CASE 60.NCE07.002
2 CCD AM.21400.068 9 BATTERY BT.00606.008
3 KEYBOARD KB.I170A.172 10 THERMAL MODULE
15W - DIS PARK
60.NCE07.010
4 UPPER CASE 60.NCE07.001 11 WLAN NI.23600.074
5 ODD 6M.NCE07.001 12 MEMORY KN.1GB07.004
6 HDD KH.16001.045 13 CPU KC.35001.DMP
7 BT ASSY BH.21100.010 14 MAIN BOARD PARK
512 HM55 W/CARD
READER
MB.NC806.001
