eMachines E732 - Replacing the Lower Cover

110 Chapter 3
Replacing the Lower Cover
1. Place the lower cover onto the device.
2. Replace the twenty three (23) screws to secure the lower cover to the device.
Step Size Quantity Screw Type
Lower Cover
(red callout)
M2.5*6.0-I 18
Battery Bay
(green callout)
M2.0*3.0-I 6
