eMachines E732 - LCD Module Disassembly Process

74 Chapter 3
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
LCD Bezel Disassembly M2.5*4.0-I 2 86.T23V7.009
LCD Panel Disassembly M2.0*4.0-I 6 86.R6Z07.002
LCD Hinge Disassembly M2.0*3.0-I 4 86.ARE07.002
