eMachines E732 - Power On Issue

108 Chapter 3
2. Replace the one (1) screw.
3. Connect the two (2) antenna cables to the WLAN module as shown.
NOTE: Cable placement is as follows: black (Main) to connector J1, white (AUX) to connector J2.
Step Size Quantity Screw Type
WLAN Board
Assembly
M2.0*3.0-I 1
