Chapter 3 67
5. Loosen the six (6) captive screws (in numerical order from 1 to 6) and remove the one (1) screw from the fan
module.
6. Carefully lift up the thermal module assembly and remove it from the mainboard.
IMPORTANT:Place the thermal module on a clean, dry surface when it is not installed.
Step Size Quantity Screw Type
Thermal Module
Disassembly
M2.0*4.0-I (green
callout)
1
6
5
1
4
3
2
