72 Chapter 3
4. Disconnect the Bluetooth cable from the Bluetooth module.
5. Remove the one (1) screw securing the Bluetooth module to the mainboard.
6. Pull the Bluetooth module away from the metal post (1) and then lift up to remove it from the mainboard (2).
Step Size Quantity Screw Type
Bluetooth Module
Disassembly
M2.0*3.0-I 1
1
2
