22. [ ] Enter the value from the
ASSEMBLY_NAME field from Table 2 of the Resume PROM information
you gathered in the Saving Resume PROM configuration information procedure, then press
Enter.
23. [ ] The system prompts:
Enter Number of Programmables (0-84) [0]:
Enter World Wide Name (WWN) Seed (0x200000-0x7FEFFFFF) [0x3B200E19]:
Vendor ID: 0x7
Model ID: 0x0C
Seed: 0x00E19
Enter PCBA Part Number (16 characters)[005348742]:
Enter PCBA Assembly Revision (3 characters)[A10]:
Enter PCBA Serial Number (16 characters)[FCNBD082021620]:
Enter Channel Technology/Speed (0x00-0xFFFF) [0x00]:
Note: In the above example, the information enclosed in brackets shows you an example of what should be
populated.
24. [ ] Continue pressing Enter to accept the default values until the system prompts: System Types:
0 - Agnostic
1 - Clariion
2 - Celerra
3 - Clariion AUX
4 - Symmetrix
5 - Centera
6 - E3 Diag Mode
Enter System Type (0-6) [2]:
25. [ ] Select Celerra and press Enter. The system prompts:
26. [ ] Enter the
Enclosure ID and press Enter. Table 4 lists the Enclosure ID and the Blades associated
with each enclosure.
Enter Enclosure ID (0-255) [0]:
Enter Rack ID (0-255) [0]:
Enter Slot ID (0-255) [0]:
Family ID:
0x0000 - No Family
0x0005 - I/O Module
0x0007 - WildcatS
0x0008 - Midplane
0x000B - Power Supply
Enter Family ID (0x00-0xFFFF) [0x08]:
FRU ID:
0x0000 - None
0x0001 - Fogbow
Enter FRU ID (0x00-0xFFFF) [0x01]:
Enter EMC Sub-Assembly Part Number (16 characters)[ ]:
Enter EMC Sub-Assembly Artwork Revision (3 characters)[ ]:
Enter EMC Sub-Assembly Assembly Revision (3 characters)[ ]:
Enter EMC Sub-Assembly Serial Number (16 characters)[ ]:
-----------------------------------
Resume PROM Unique Information Area
-----------------------------------
Enter NAS Enclosure ID (0x00-0xFFFFFFFF) [0x01]: 0
