# /nasmcd/sbin/navicli -h <SPA_IP_Address> storagegroup -list -gname "~filestorage"
Example:
# /nasmcd/sbin/navicli -h 10.6.4.126 storagegroup –list –gname "~filestorage"
Storage Group Name: ~filestorage
Storage Group UID: 3E:86:BB:3D:70:64:DF:11:9C:6F:00:60:16:36:9C:7D
HBA/SP Pairs:
HBA UID SP Name SPPort
------- ------- ------
50:06:01:60:BC:E0:08:9F:50:06:01:61:3C:E0:08:9F SP B 0
50:06:01:60:BC:E0:08:9F:50:06:01:69:3C:E0:08:9F SP B 1
50:06:01:60:BC:E0:08:9F:50:06:01:60:3C:E0:08:9F SP A 0
50:06:01:60:BC:E0:08:9F:50:06:01:68:3C:E0:08:9F SP A 1
HLU/ALU Pairs:
HLU Number ALU Number
---------- ----------
0 0
1 1
2 2
3 3
4 4
5 5
16 16
17 17
Shareable: YES
Task 10: Configure the HBA/Initiator Records
The replacement BE contains a new midplane that is assigned different identifiers than were assigned to
the midplane in the faulted BE.
To configure the HBA/Initiator records maintaining the connections running from the replacement BE to the
storage array or switch:
 Set up the replacement BE
 Remove the old initiator records
 Collect the new WWNs
 Recreate the initiator records
 Verify the new connections
 Configure the Blades
 Test the functionality of the system
Set Up the Replacement BE
1. [ ] Add the replacement BE to the database, and set up the enclosure ID on the backplane by issuing:
# /nasmcd/sbin/setup_enclosure -addEnclosure <Blade_enclosure_ID>
Note: If the setup_enclosure -addEnclosure command fails, use the setup_enclosure
-checkCable and setup_enclosure -checkSystem commands to identify the reason for the failure.
