# /nasmcd/sbin/navicli -h 10.6.4.126 storagegroup –list –host
Storage Group Name: Celerra_naut3
Storage Group UID: 3E:86:BB:3D:70:64:DF:11:9C:6F:00:60:16:36:9C:7D
HLU/ALU Pairs:
HLU Number ALU Number
---------- ----------
5 35
4 34
1 31
2 32
0 30
3 33
Shareable: YES
 If you are replacing a Blade enclosure on any other VNX Unified or File system, use the following
command to complete this step:
# /nasmcd/sbin/navicli -h <SPA_IP_Address> storagegroup -list -gname "~filestorage"
Example:
# /nasmcd/sbin/navicli -h 10.6.4.126 storagegroup –list –gname "~filestorage"
Sample Output:
Storage Group Name: ~filestorage
Storage Group UID: 3E:86:BB:3D:70:64:DF:11:9C:6F:00:60:16:36:9C:7D
HLU/ALU Pairs:
HLU Number ALU Number
---------- ----------
5 35
4 34
1 31
2 32
0 30
3 33
Shareable: YES
Collect the New WWNs
To collect the WWNs assigned to the replacement enclosure:
7. [ ] Start the PXE Services by typing:
# /nasmcd/sbin/t2pxe -s -R 8
8. [ ] PXE Boot the Blades in the replacement BE:
Note: If this command fails to PXE boot the Blade, repeat until the PXE boot completes.
# /nasmcd/sbin/t2tty -p <slot_number>
where <
slot_number> is the slot number of the Blade(s) in the replacement BE.
9. [ ] Stop the PXE Services:
# /nasmcd/sbin/t2pxe –e
10. [ ] Check the fault LED on the front of the BE Figure 20. If the LED is amber, there is still a faulted
component in the BE or the BE is still faulted.
