B Technical specifications
This chapter lists the specifications for the hardware and the AC adapter.
B.1 Physical specifications
Specification Value
Weight Approximately 1330 grams
Height x width 7.75" x 5.5" inches
Display 5.7 inch color VGA resistive touchscreen
640 x 480 pixel
Buttons (front of the Trex
unit)
X button - similar to a Back key
4 arrow buttons to navigate menus
Checkmark - similar to an Enter key
USB Micro USB connector. USB 2.0
Remove the USB cable from the Trex unit before connecting to a
device.
B.2 Communication module specifications
Device Communicator communication module
Terminal Overview
HART terminals The terminals enable HART communication with the Trex
unit.
Connectors: Two banana jack plugs.
Internal fuse rating: 50 mA
Fieldbus (FF) terminals The terminals enable FOUNDATION fieldbus
communication with the Trex unit.
Connectors: Two banana jack plugs.
User Guide Technical specifications
September 2021
User Guide 183
