Procedure
1. Connect to the HART device.
2. Go to the parameter you want to change.
See the device documentation for more information. Each device has different
menus.
3. Make the desired change.
The changed parameter is highlighted yellow.
4. Tap OK.
5. Tap the Send icon in the upper right corner.
A list of all the changes you made is displayed.
6. Review the change.
Tap Discard to undo the change and close the screen. Tap Cancel to keep the
change and send it to the device at a later time.
7. Tap Send.
The change is sent to the device. The yellow highlight is removed from the changed
parameters.
3.14.5 Edit a HART configuration
Prerequisites
Note
Do not edit a configuration on the Trex unit while you are connected to the Configuration
Management PC application.
Procedure
1. In the Field Communicator application, tap HART Offline.
2. Tap Offline Config → Edit Existing.
3. Tap the column heading to sort configurations by File Name or Tag. Select the
configuration you want to edit, and tap OK.
4. Select and edit the parameters.
5. Tap the checkbox to mark the parameter for writing.
Note
Unmarked parameters are saved but not sent when you transfer the configuration
to a connected device.
6. Tap Save when you finish editing the parameters.
7. If necessary, enter a new configuration name.
8. Tap OK.
3.14.6 Display the HART short tag or long tag
You can select the HART short or long tag to display for HART revision 6 or higher devices.
By default, HART revision 7 devices display the long tag. The option will not display for
earlier devices.
User Guide Field Communicator application
September 2021
User Guide 91
