Emerson AMS Trex Device Communicator - Trex Unit Shortcut Bar

• Time
• Paired icon
• USB icon
• Wireless icon
• Power module icon
• Pull-down tab
Figure 2-15: Status bar
Related information
Shortcut bar
2.9.3 Shortcut bar
The shortcut bar lets you access additional settings for the Trex unit and the Field
Communicator application.
To view the shortcut bar, tap Settings on the Home screen or tap the status bar.
Figure 2-16: Shortcut bar
Option Description
Home
Close the shortcut bar and return to the Home screen.
Apps
View the open applications or close an application.
Brightness
Adjust the screen brightness.
Wi-Fi
Configure wireless settings.
User Guide AMS Trex Device Communicator overview
September 2021
User Guide 29
