Electrical Specification
Input protection 1.6A 250VAC Fuse
No load power consumption <0.5W max. at nominal input and no load output
Output voltage 15 V
Output current 4.33 A
Ripple and noise 1% Vout
Hold up time 10ms at nominal input and full load output
No load operation Yes, to protect power supply and system from damage
Short circuit protection Auto recovery, cannot exceed 8A max. after 1 minute at
nominal input line.
Over current protection 150-200%, foldback type, auto recovery
Over voltage protection 110-140%, voltage limiting, recycle input to recover
Operating temperature range 0°C to + 50°C
Operating humidity 8-90% RH non-condensing
Operating altitude Maximum of 2000 meters
Storage temperature range -20°C to +70°C
Storage humidity 5-95% RH non-condensing
Cooling Free air convection
Dimensions 119 x 54x 36mm
Weight 0.33 kg
Withstand voltage I/P-O/P (FG): 3kVAC / 10 mA / 1 minute
EMI EN55022: 2006 Class B, EN61000-3-2:2006, EN61000-3-3:
1995+A1: 2001+A2:2005 EN55024:1998+A1: 2001+A2:
2003, IEC61000-4-2, -3, -4, -5, -6+A1:2004, -8, -11
Safety CB (IEC60950-1: 2001), TUV GS (EN60950-1: 2005 +A1 + A2),
cUL, CE, VCCI
Approvals
cUL North America, TUV GS Europe, Japan PSE, IRAM Argentina, Russian EAC, Kazakhstan
EAC, South Africa SANS IEC 60 950, Korean EK, China CCC.
WEEE 2012/19/EU, RoHS (2011/65/EU)
Technical specifications User Guide
September 2021
188 User Guide
