Figure 3-6: Menu screen for a connected HART device
Option Description
Connect or Disconnect Tap Connect to return to the Connect - Select screen and connect to
a device. Tap Disconnect to stop communicating with a device. The
Trex unit also stops powering the device when you tap Disconnect.
Favorites
Save frequently used menu items to a list for quick access. The
Favorites option is available for only HART devices.
Simulate
Simulate a connection to a live HART or FOUNDATION fieldbus device,
depending on if you selected HART Offline or Fieldbus Offline. This
option is displayed only if a device is not connected to the Trex unit.
Save Config
Save a configuration for this device to the AMS Trex unit.
Send Config
Send a configuration to a connected HART device. This option is
displayed only if a device is connected to the Trex unit.
Offline Config
Create or edit a configuration on the AMS Trex unit.
Field Communicator application User Guide
September 2021
66 User Guide
