Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
October 2019
113
Section 13: Parts List and Drawings
Parts List and Drawings
Figure 95 Thrust Block Assembly
Table 28. Thrust Block Assembly
Item Qty Description
75.1 1 O-ring
75.2 1 Thrust block housing
75.3* 1 Greaser
75.4 4 Thrust washer
75.5 1 Stem nut
75.6* 2 Thrust bearing
75.7* 1 Quad ring
75.8 1 Lower ring nut
* Recommended spare parts
