Emerson Daniel Ultrasonic 3410 Series

Table C-1: CPU Module labeling and LED functions (continued)
DHCP Dynamic Host Protocol Server -
enables you to communicate
with a Daniel meter that is not
connected to a network.
When the CPU Module switch is
in the ON position, the meter is
enabled to act as a DHCP server
for a single DHCP client
connected to the Ethernet port
using a crossover cable. This
should be used for peer to peer
connections only.
When the connection is made,
select to use the Meter Name in
the meter instead of the Meter
Directory Name in order to
keep all log files and
configurations separate from
each meter.
Switch position
• ON - the meter is enabled
to act as a DHCP server for a
single DHCP client
• OFF - disables the DHCP
server
PORT A PORT A override - RS-232
serves as an override during
meter commissioning to
establish communications and
in the event the user cannot
communicate with the meter
due to an inadvertent
communication configuration
change. The override period is
for two minutes. Supports:
• auto-detected ASCII (Start
bit 1, Data Bit 7, Parity Odd/
Even, Stop Bit 1)
• RTU (Start Bit 1, Data Bit 8,
Parity none, Stop Bit 1).
• Modbus protocols RS-232
Baud rate=19,200 Modbus
ID=32
Switch position
• ON - enables RS-232 PORT
A override
• OFF - (default setting)
disables RS-232 PORT A
override
MEAS System color indicates
metrology mode Acquisition
mode
Measurement mode
LED status
• Red flashing LED
• Solid red the Acquisition
Module is not
communicating with the
CPU Module
• Green flashing LED
PWR 3.3V Power Indicator Solid Green
LED 4 Not used
LED 5 Not used
Upgrade kit instructions 3410 Communication and Output settings
P/N 3-9000-784 July 2019
3410 Series Electronics Upgrade kit instructions 77
