4 • iPro I/O Module Installation and Operation Manual 026-1741 Rev 0
1.7 Analog Output
Specifications
The following tables outline the analog output
specifications. The 10 DIN IPG215D model requires an
additional 24VAC power supply to the analog output
connector block in order to supply power to the analog
outputs. A separate transformer other than the controller
supply power is required to power the 10 DIN’s analog
outputs. When purchasing one of the Emerson control
panels, the analog output wiring and 24 VAC supply
wiring is factory-wired to a terminal block. Installers only
need to make connections for signal wiring between the
factory terminal block and device in the field to be
controlled.
CAUTION: The electrical devices controlled
by these analog outputs must be powered
separately with another transformer (do not
use the same secondary of the controller’s
power) in order to prevent the outputs from
malfunctioning or being damaged.
10 DIN 215D Analog Output Specifications
Type
Opto-insulated with separate
24VAC/DC power supply
Number of outputs 6
Type of analog
output
(configurable via
software
parameter)
4 fixed outputs 0 to 10VDC
(Out 1 to Out 4)
2 configurable outputs 0 to 10VDC,
4 to 20mA (Out 5 and Out 6)
Maximum load
40mA (Out1 to Out 4)
20mA (Out 5 and Out 6) max with
configured outputs 0 to 10VDC
400Ω max with configured outputs
4 to 20mA
22Ω per live analog output
Table 1-6 - 10 DIN 215 Analog Output Specifications
