Emerson iPro IPG215D - Digital Input Specifications; Relay Output Specifications

Digital Input Specifications General Description • 3
1.5 Digital Input
Specifications
The below tables outline the digital input specifications.
1.6 Relay Output
Specifications
The below tables outline the relay output specifications.
CAUTION: Use another transformer (do
not use the same secondary of the
controller’s power) in order to prevent the
inputs from malfunctioning or being damaged.
10 DIN 215D Digital Input Specifications
Type
(configurable via
software
parameter)
Opto-insulated free or live contact
(24VAC/DC)
External power 24VAC/DC ±20%
Number of inputs 20
Digital input status
variation detection
time
100ms (depends on the cycle time set
by the user in the given application)
Table 1-4 - 10 DIN 208D Digital Input Specifications
CAUTION: If the digital inputs are used with
voltage, use another transformer (do not use
the same secondary of the controller’s power)
in order to prevent the inputs from
malfunctioning or being damaged.
10 DIN 215D Relay Output Specifications
Type Relays with NO contacts
Number of outputs 15
Maximum load 5A(250VAC) SPST 5(2)A
Table 1-5 - 10 DIN 208D Relay Output Specifications
WARNING: Verify the capacity of the output
used. There is double insulation between the
digital outputs and the low voltage of the rest of
the circuit. Do not use different voltages for the
various groups of relays or within each group.
