I/O Capacity General Description • 1
1 General
Description
The I/O Module is a PLC application that uses the iPro
hardware platform as a source of auxiliary input and
output capacity for the E2E supervisor controller. The I/O
Module is compatible with E2E version 4.09F04 or later.
The I/O Module can be used with RX, BX, or CX models
of the E2E. The I/O Module is sold in 10 DIN IPG215D
PLC hardware model depending on what I/O capacity is
needed.
The I/O Module inputs and outputs are fully configurable
from the E2E controller via BACnet MS/TP. The I/O
Module can be used with the Emerson E2E controller to
gather data from analog or digital inputs, control the I/O
Module’s Onboard relays, and provide an analog output
signal through I/O Module’s Onboard analog outputs.
Both I/O Module hardware models can also can provide
+5VDC or +12VDC power supply for using transducers or
other input devices that require a power supply.
The I/O Module communicates with E2E via
BACnet/MSTP protocol and can be deployed anywhere
wherein a new or auxiliary I/O capacity is needed. Once
BACnet MS/TP communication between the I/O Module
and E2E is established, each input and output can be
configured completely from the E2E screen and keyboard.
The Visograph display is used as a local display where the
PLC is mounted and is used to display input and output
status, configure BACnet serial settings, and view system
information.
1.1 I/O Capacity
The following table outlines the Onboard I/O capabilities
of each PLC model. Technical specifications of each input
or output can be found in Section 1.4 to Section 1.7.
1.2 Ordering and Part
Numbers
Feature 10 DIN IPG215D
Analog Inputs 10
Digital Inputs 20
Analog Outputs 6
Relay Outputs 15
Remote Display Yes
Table 1-1 - PLC Onboard I/O Capabilities
Emerson Part
Number
Description
851-4445 E2E I/O Module Panel
818-9205 Replacement Visograph Display
818-9057 Replacement 10 Din iPro Large
Table 1-2 - Module Ordering Information and Part Numbers
