6 • iPro I/O Module Installation and Operation Manual 026-1741 Rev 0
12 Pb8
Configurable analog input 8 (NTC, PTC, 0 to 20mA, 4 to 20mA, 0 to 10V, 0 to 1V, 
0 to 5V, DI)
13 Pb9
Configurable analog input 9 (NTC, PTC, 0 to 20mA, 4 to 20mA, 0 to 10V, 0 to 1V, 
0 to 5V, DI)
14 Pb10
Configurable analog input 10 (NTC, PTC, 0 to 20mA, 4 to 20mA, 0 to 10V, 0 to 1V, 
0 to 5V, DI)
15 +5V Additional power +5VDC
16 +12V Additional power +12VDC
21 Out 1 Opto-insulated analog output 1 (0 to 10V)
22 Out 2 Opto-insulated analog output 2 (0 to 10V)
23 Out 3 Opto-insulated analog output 3 (0 to 10V)
24 Out 4 Opto-insulated analog output 4 (0 to 10V)
25 GND (-) Common opto-insulated analog output
26 Out 5 Analog output 5 (0 to 10V, 4 to 20mA, Opto-insulated relay)
27 Out 6 Analog output 6 (0 to 10V, 4 to 20mA, Opto-insulated relay)
28 Supply Power for opto-insulated analog outputs as 24VAC or 24VDC (-)
29 Supply Power for opto-insulated analog outputs as 24VAC or 24VDC (+)
30 GND (-) Common opto-insulated analog output
40 DI1 Opto-insulated digital input 1
41 DI2 Opto-insulated digital input 2
42 DI3 Opto-insulated digital input 3
43 DI4 Opto-insulated digital input 4
44 DI5 Opto-insulated digital input 5
45 DI6 Opto-insulated digital input 6
46 DI7 Opto-insulated digital input 7
47 DI8 Opto-insulated digital input 8
48 DI9 Opto-insulated digital input 9
49 DI10 Opto-insulated digital input 10
50 GND (-) Reference “-” for opto-insulated digital inputs 1 to 20 (if inputs 24VAC or 24VDC)
51 DI11 Opto-insulated digital input 11
52 DI12 Opto-insulated digital input 12
53 DI13 Opto-insulated digital input 13
Input
No.
Type of Input Description
Table 1-7 - 4 DIN 208D Input Connector Descriptions
