14 • iPro I/O Module Installation and Operation Manual 026-1741 Rev 0
Contact Characteristics
Contact Material Silver Alloy
Contact Rating (resistive) 30 A NO Contacts/40 A NC Contacts 277VA C
Max Switching Voltage 277V
Max Switching Current 40A
HP 2 @ 277VAC
HP 1 @ 120VAC
Coil Characteristics
Voltage Range 12 to 277VAC
Average Consumption 2VA
Table 2-1 - 10 DIN Panel Pilot Relay Specifications
Figure 2-7 - 10 DIN Panel Relay Wiring
