8.7 Configuring events
An event occurs if the real-time value of a user-specified process variable varies above or below a
user-specified value, or inside or outside a user-specified range.
Events can be used to initiate specific transmitter actions. Possible actions include:
• Start zero
• Reset mass total
• Reset volume total
• Reset gas standard volume total
• Reset all totalizers
• Start/stop all totalizers
Up to five events can be configured. You can define more than one event on a single process variable
if desired.
You can configure an event to initiate multiple actions, e.g., you can configure Event 1 to reset both
the mass total and the volume total.
Table 8-4 Effect of flow direction on frequency output, discrete output, totalizers, and digital
communications
Flow direction value
Forward flow
(1)
(1) Process fluid flowing in same direction as flow direction arrow on sensor.
Frequency
output Discrete output
(2)
(2) Applies only if the discrete output has been configured to indicate flow direction. See Section 6.7.2.
Flow totals
Flow values via
digital comm.
Forward only Increase Forward Increase Positive
Reverse only 0 Hz Forward No change Positive
Bidirectional Increase Forward Increase Positive
Absolute value Increase Forward Increase Positive
(3)
(3) Refer to the digital communications status bits for an indication of whether flow is positive or negative.
Negate/Forward Zero
(3)
Reverse No change Negative
Negate/Bidirectional Increase Reverse Decrease Negative
Flow direction value
Zero flow
Frequency
output Discrete output Flow totals
Flow values via
digital comm.
All 0 Hz Reverse No change 0
Flow direction value
Reverse flow
(4)
(4) Process fluid flowing in opposite direction from flow direction arrow on sensor.
Frequency
output Discrete output Flow totals
Flow values via
digital comm.
Forward only 0 Hz Reverse No change Negative
Reverse only Increase Reverse Increase Negative
Bidirectional Increase Reverse Decrease Negative
Absolute value Increase Forward Increase Positive
(3)
Negate/Forward Increase Forward Increase Positive
Negate/Bidirectional Increase Forward Increase Positive
