40 Micro Motion
®
Model 2400S Transmitters with Analog Outputs
Required Transmitter Configuration
6.4.2 Volume flow units
The default volume flow measurement unit is
L/s. Two different sets of volume flow measurement
units are provided:
• Units typically used for liquid volume – see Table 6-3
• Units typically used for gas volume– see Table 6-4
By default, only liquid volume flow units are listed. To access the gas volume flow units, you must
first use ProLink II to configure Vol Flow Type. See Section 8.2.
Note: The Communicator cannot be used to configure gas volume flow units. If a volume flow unit for
gas is configured, the Communicator will display “Unknown Enumerator” for the units label.
If the volume flow unit you want to use is not listed, you can define a special measurement unit for
volume flow (see Section 8.3).
Table 6-2 Mass flow measurement units
Mass flow unit
Unit descriptionDisplay ProLink II Communicator
G/S g/s g/s Grams per second
G/MIN g/min g/min Grams per minute
G/H g/hr g/h Grams per hour
KG/S kg/s kg/s Kilograms per second
KG/MIN kg/min kg/min Kilograms per minute
KG/H kg/hr kg/h Kilograms per hour
KG/D kg/day kg/d Kilograms per day
T/MIN mTon/min MetTon/min Metric tons per minute
T/H mTon/hr MetTon/h Metric tons per hour
T/D mTon/day MetTon/d Metric tons per day
LB/S lbs/s lb/s Pounds per second
LB/MIN lbs/min lb/min Pounds per minute
LB/H lbs/hr lb/h Pounds per hour
LB/D lbs/day lb/d Pounds per day
ST/MIN sTon/min STon/min Short tons (2000 pounds) per minute
ST/H sTon/hr STon/h Short tons (2000 pounds) per hour
ST/D sTon/day STon/d Short tons (2000 pounds) per day
LT/H lTon/hr LTon/h Long tons (2240 pounds) per hour
LT/D lTon/day LTon/d Long tons (2240 pounds) per day
SPECL special Spcl Special unit (see Section 8.3)
