42 Micro Motion
®
Model 2400S Transmitters with Analog Outputs
Required Transmitter Configuration
6.4.3 Density units
The default density measurement unit is
g/cm3. See Table 6-2 for a complete list of density
measurement units.
Table 6-4 Volume flow measurement units – Gas
Volume flow unit
Display ProLink II Communicator Unit description
NM3/S Nm3/sec Not available Normal cubic meters per second
NM3/MN Nm3/min Not available Normal cubic meters per minute
NM3/H Nm3/hr Not available Normal cubic meters per hour
NM3/D Nm3/day Not available Normal cubic meters per day
NLPS NLPS Not available Normal liter per second
NLPM NLPM Not available Normal liter per minute
NLPH NLPH Not available Normal liter per hour
NLPD NLPD Not available Normal liter per day
SCFS SCFS Not available Standard cubic feet per second
SCFM SCFM Not available Standard cubic feet per minute
SCFH SCFH Not available Standard cubic feet per hour
SCFD SCFD Not available Standard cubic feet per day
SM3/S Sm3/S Not available Standard cubic meters per second
SM3/MN Sm3/min Not available Standard cubic meters per minute
SM3/H Sm3/hr Not available Standard cubic meters per hour
SM3/D Sm3/day Not available Standard cubic meters per day
SLPS SLPS Not available Standard liter per second
SLPM SLPM Not available Standard liter per minute
SLPH SLPH Not available Standard liter per hour
SLPD SLPD Not available Standard liter per day
SPECL special Spcl Special unit (see Section 8.3)
Table 6-5 Density measurement units
Density unit
Unit descriptionDisplay ProLink II Communicator
SGU SGU SGU Specific gravity unit (not temperature corrected)
G/CM3 g/cm3 g/Cucm Grams per cubic centimeter
G/L g/l g/L Grams per liter
G/ML g/ml g/mL Grams per milliliter
KG/L kg/l kg/L Kilograms per liter
KG/M3 kg/m3 kg/Cum Kilograms per cubic meter
LB/GAL lbs/Usgal lb/gal Pounds per U.S. gallon
LB/CUF lbs/ft3 lb/Cuft Pounds per cubic foot
LB/CUI lbs/in3 lb/CuIn Pounds per cubic inch
ST/CUY sT/yd3 STon/Cuyd Short ton per cubic yard
