Configuration and Use Manual 41
Required Transmitter Configuration
Required Configuration Optional ConfigurationUsing the TransmitterFlowmeter Startup
Table 6-3 Volume flow measurement units – Liquid
Volume flow unit
Display ProLink II Communicator Unit description
CUFT/S ft3/sec Cuft/s Cubic feet per second
CUF/MN ft3/min Cuft/min Cubic feet per minute
CUFT/H ft3/hr Cuft/h Cubic feet per hour
CUFT/D ft3/day Cuft/d Cubic feet per day
M3/S m3/sec Cum/s Cubic meters per second
M3/MIN m3/min Cum/min Cubic meters per minute
M3/H m3/hr Cum/h Cubic meters per hour
M3/D m3/day Cum/d Cubic meters per day
USGPS US gal/sec gal/s U.S. gallons per second
USGPM US gal/min gal/min U.S. gallons per minute
USGPH US gal/hr gal/h U.S. gallons per hour
USGPD US gal/d gal/d U.S. gallons per day
MILG/D mil US gal/day MMgal/d Million U.S. gallons per day
L/S l/sec L/s Liters per second
L/MIN l/min L/min Liters per minute
L/H l/hr L/h Liters per hour
MILL/D mil l/day ML/d Million liters per day
UKGPS Imp gal/sec Impgal/s Imperial gallons per second
UKGPM Imp gal/min Impgal/min Imperial gallons per minute
UKGPH Imp gal/hr Impgal/h Imperial gallons per hour
UKGPD Imp gal/day Impgal/d Imperial gallons per day
BBL/S barrels/sec bbl/s Barrels per second
(1)
(1) Unit based on oil barrels (42 U.S gallons).
BBL/MN barrels/min bbl/min Barrels per minute
(1)
BBL/H barrels/hr bbl/h Barrels per hour
(1)
BBL/D barrels/day bbl/d Barrels per day
(1)
BBBL/S Beer barrels/sec bbbl/s Beer barrels per second
(2)
(2) Unit based on beer barrels (31 U.S gallons).
BBBL/MN Beer barrels/min bbbl/min Beer barrels per minute
(2)
BBBL/H Beer barrels/hr bbbl/h Beer barrels per hour
(2)
BBBL/D Beer barrels/day bbbl/d Beer barrels per day
(2)
SPECL special Spcl Special unit (see Section 8.3)
