Reference Manual
00809-0100-4840, Rev. BA
July 2008
Rosemount 3100 Series
www.rosemount.com
Section 4 Starting up
Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-2
Programming The Rosemount 3101 . . . . . . . . . . . . . . . . . page 4-4
Programming The 3102 and The 3105 . . . . . . . . . . . . . . . page 4-12
Final Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-28
Power Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-28
SAFETY MESSAGES Procedures and instructions in this section may require special precautions to
ensure the safety of the personnel performing the operations. Information that
raises potential safety issues is indicated by a warning symbol ( ). Refer to
the safety messages listed at the beginning of each section before performing
an operation preceded by this symbol.
Explosions could result in death or serious injury:
Verify that the operating environment of the gauge is consistent with the appropriate
hazardous locations certifications.
Before connecting a HART-based communicator in an explosive atmosphere, make
sure the instruments in the loop are installed in accordance with intrinsically safe or
non-incendive field wiring practices.
Do not remove the gauge cover in explosive atmospheres when the circuit
is alive.
Failure to follow safe installation and servicing guidelines could result in death or
serious injury:
Make sure only qualified personnel perform the installation.
Use the equipment only as specified in this manual. Failure to do so may impair the
protection provided by the equipment.
Do not perform any service other than those contained in this manual unless you are
qualified.
